Patriot Solarguard 500 Solar Powered Fence Charger

Patriot Solarguard 500 Solar Powered Fence Charger

PATRIOT

Options

SolarGuard 500™ Solar Energizer

SG500

Powers up to 100 acres / 30 miles / 40 hectares / 50 km of fence

0.50 J maximum output energy (0.65 J stored energy)

FEATURES & BENEFITS

Simple and intuitive
· Solar panel and battery integrated in one convenient robust case
· Housing for convenient stowing of fence leads when not in use
· Single flashing LED indicates fence pulse
· Fit and replace the battery with ease

Truly portable
· Easy to carry portable housing
· Allows mounting to existing steel post or wood post

Delivers power where it counts
· More powerful than comparable energizers
· Reliable year round performance in harsh weather
· Includes leads for connecting to existing fence
· Terminals contain metal insert to ensure robust fence connection

Safe and long lasting
· Complies with IEC safety standards
· 3 year warranty
· Rechargeable internal battery included

*Single light tester while supplies last. Can be substituted with similar priced item.

TECHNICAL INFORMATION

DISTANCE RANGE (miles)	30 miles
DISTANCE RANGE (acres)	100 acres
PEAK OUTPUT ENERGY (UP TO)	0.50 J
PEAK STORED ENERGY (UP TO)	0.65 J
OUTPUT VOLTAGE @ 500 Ω	4,500 V
OUTPUT VOLTAGE @ 1,000 Ω	6,200 V
CURRENT CONSUMPTION	50mA @ 13 V
RECOMMENDED SOLAR PANEL	9.6 W
